Makita Track Saw Parallel Guide Extension Set

Repeatable rips with the Makita track saw

This jig makes it easy to cut precise strips of exactly the same width when panel cutting.

Two side fences are mounted on the guide rail. The required dimension is set with the adjustable stops.

- Huge time saving when cutting panel strips, as no more measuring or marking is necessary. - For cuts wider than 300 mm - Toolless mounting on the guide rail Print settings: PETG layer height of 0.3mm should work fine

Hardware: 1x M5x30 Hex head bolt 2x M5x10 Socket head screw 3x M5 Hex nut 1x M4 Hex head bolt 1x M4 Heat-Set inserts for plastic (brass) 2x T-Track 17x10mm, ~800mm, aluminium profile

T-Track or C-Profile (not affiliated)
