Big filament spool holder for 2,6 kg or 1 kg spools

Big filament spool holder for 2,6 kg or 1 kg spools

You can simply place the spool holder or screw it on the IKEA Lack printer enclosure.

To change the filament, simply remove the screws on the top and slide the spoolholder out to the side.

Dimensions of the spool holder:

- up to 300 mm spool diameter - 51 mm diameter spool rod - 108 mm spool rod width To assemble the holder you need:

- 8x M4x10 DIN 912 Screw - 8x M4 DIN 934 Hex nut - 2x M5x50 DIN 912 Screw - 2x M5 DIN 934 Hex nut The bottomplate with holes is designed for 4 mm countersunk wood screws
