Camera Tripod Mount Adapter for Ender 3 V2 Arm

I loved the strong 'Ultimate Sturdy Octoprint / Pi Camera Mount' arm from Stewpercharged ( https://www.thingiverse.com/thing:3374914 ), but I didn't want to mount a Pi Cam (using the 'Mendel90 Raspberry Pi cam holder' from JakesterDS — https://www.thingiverse.com/thing:1714123 ).

I wanted to mount my Logitech C920, which has a tripod screw mount, like any standard camera and most webcams. So I took a Tripod mounting plate, which accepts standard tripod screws (you can find them on eBay or Amazon, like the ones I use from Smallrig: https://www.amazon.com/gp/product/B087BXC6GK?ie=UTF8&psc=1&linkCode=sl1&tag=mmjjg-20&linkId=76deb9493f871b45f0bb76063c9eeeab&language=en_US&ref_=as_li_ss_tl ), and mixed it together with the mounting point from JakesterDS's cam holder, and made this.

You basically:

- Print the Ultimate Sturdy Mount.

- Print this file.

- Slide the Ultimate Sturdy Mount into the rails on the left side of the Ender 3 V2.

- Affix this adapter plate to that mount using a small metric nut and bolt.

- Use a tripod screw to mount your camera to the adapter plate.

Print Settings

Printer Brand:

Creality

Printer: Ender 3

Rafts:

No

Supports: No

Resolution:

200

Infill: 20

Filament: ZYLTech PLA Black

Category: 3D Printer Accessories
