Fan Adapter 40mm to 60mm @45deg

Customized version of https://www.thingiverse.com/thing:735038

Created with Customizer! https://www.thingiverse.com/apps/customizer/run?thing_id=735038

Convert a 60mm fan to a 40mm mounting for extra cooling on a 3D printer.

An extra 10mm was added to the 40mm end to allow clearance for the screws.

Instructions

Using the following options:

t_wall = 4

d_fan1 = 40

ls_fan1 = 34

ds_fan1 = 4.3

d_fan2 = 60

ls_fan2 = 52

ds_fan2 = 4.3

l_mani1 = 10

a_cone = 100

a_mani = 45

az_mani = 0

n_pipe = 1

n_angle = 0.501

$fn = 50

Category: 3D Printer Parts
