MPCNC Primo J: Mister Mount

I designed this thing to mount a mister to my MPCNC Primo J cnc router. To use this thing, you will need:

1@ Printed mount

1@ Rattmmotor brand mister nozzle ( https://www.amazon.com/gp/product/B0773LG1F9/ref=ppx_yo_dt_b_asin_title_o03_s00?ie=UTF8&psc=1 )

1@ M3-10 allen head bolt w/nut

1@ 1/4-20x1.5" bolt w/ nut (optional)

I printed with 4 walls using PETG, and it feels very solid... nearly zero deflection even when the hose is extended straight out (parallel to bed). The clamp is secured to the top of the z-tubes using a captured M3 nut and bolt. The mister is fixed to the mount with the 4 included M4 bolts (remove the stock mounting bracket and save the screws). Optionally a the 1/4-20 bolt can be used to make it even stronger, or it can just be used as a temporary pin to help hold the mister in place while installing the M4 bolts from below. There is a hex recess to capture a 1/4-20 nut if it is to be used permanently.

Print Settings

Rafts:

No

Supports: No
