Kapton Tape Dispenser Conversion

(Sorry about the image, it's imported from Thingiverse and I'm too lazy to reupload)

I bought a set of Kapton tape and I wanted a dispenser. I found an old one used for masking tape and printed out these things that match the thicknesses of the tape rolls. It uses a 1/8th inch steel rod as the central pivot.

Kapton Tape: https://www.amazon.com/gp/product/B072Z92QZ2/ref=ppx\_yo\_dt\_b\_asin\_title\_o09\_s00?ie=UTF8&psc=1&pldnSite=1

Reddit Discussion: https://www.reddit.com/r/functionalprint/comments/d7u071/converted\_a\_masking\_tape\_dispenser\_for\_kapton/

(Verbose file names are overrated)

Print instructions

Category: Tool Holders & Boxes Summary

I bought a set of Kapton tape and I wanted a dispenser. I found an old one used for masking tape and printed out these things that match the thicknesses of the tape rolls. It uses a 1/8th inch steel rod as the central pivot.

Kapton Tape: https://www.amazon.com/gp/product/B072Z92QZ2/ref=ppx\_yo\_dt\_b\_asin\_title\_o09\_s00?ie=UTF8&psc=1&pldnSite=1

Reddit Discussion: https://www.reddit.com/r/functionalprint/comments/d7u071/converted\_a\_masking\_tape\_dispenser\_for\_kapton/

(Verbose file names are overrated)

Print Settings

Printer: Folger Tech FT-5 (V1)

Rafts: No

Supports: No

Resolution: 0.2mm

Infill: 15%

Filament: 3D Solutech PLA

Notes:

The acute angles inside of the pieces can be a bit tricky if your bed adhesion isn't good!

Post-Printing

Other things needed to make the holder

- A masking tape holder

- A 1/8th inch metal rod cut to the length that fits in the masking tape holder.
