Spool Holder for Kingroon KP3S Pro (S1) - Low height spool-holder Remix + Filler

This is a top spool holder for Kingroon KP3S Pro S1. (Mine is from Sliceworx.) So far it has been working great for me.

The arm is a remix of Low hight spool-holder v23 for Kingroon KP3S, Aquila & Ender3

So that the roller of the Filler - The Customizable Filament Holder fits in the arm.

Needed files from the Filler Customizable Filament Holder:

- 3DPNFilHoldGuide.stl - 3DPNFilHoldRoller.stl - FillerPlasticBearing.stl (optional if not using two 608 bearings) I used two bearings from Amazon: https://www.amazon.com/s?k=608+bearing&crid=1H8BBV9P3W24J&sprefix=608+bearing%2Caps%2C95&ref=nb_sb_noss_1

The specific ones I ordered were: https://www.amazon.com/dp/B07R7PR72H?psc=1&ref=ppx_yo2ov_dt_b_product_details

Also needed are two M5x28 or M5x30 screws, the stock ones on the top may not be long enough.

Printed here in Sliceworx Robitobi Green and Electric Purple. It rolls soooo smooth.

NOTES:

Be mindful of the back clearance and printing anything tall at the back of the build plate. It could bump into the spool as it goes up.

You can also mirror it in the slicer so it connects on the left side instead of the right.

===================================

Another top spool holder option, is the holder created by auroratechchannel

https://www.printables.com/model/352124-kingroon-kp3s-pro-kp3s-pro-kp3s-pro-s1-handle-and-
