FGC68 MKII tipx edition: Dye Half mag UAL Upper and lower set for first strike use

11-10-2024 M5 nut lower have been added. for a stronger connection

it will use a 30mm long M5 bolt with 3d printed grips -------

FGC68 GEN2 Updarted

the link to the new manuals and parts list can be found here https://drive.google.com/drive/folders/1POafTye0p9ps3qhr2-nWT2uAPL3kko1u?usp=sharing

____________________________

this lower and Upper will work with the basic FGC68-MKII parts. this set will make it possible to use dye half mags with the FGC68 platfrom

the FGC68 starter set can be found here: https://www.printables.com/model/87803-fgc-68-base-package-starter-set-for-tipx-tcr-magfe

the collection of FGC68 parts can be found here: FGC68 MKII https://www.printables.com/social/180009-untangleworks/collections/88908

FGC68 MKI https://www.printables.com/social/180009-untangleworks/collections/88907

some of the installation steps that are different from the TIPX lower can be fund in the images for now

-

marker parts: long range kit for TIPX or TCR internals for first strike use

I have not tested if the stock TIPX round shaped breach will match well with the Plant eclipse followers... for round-ball only use

- mags parts:

self made dye half mags or the UNW DHM mag shells. and you will need the PE followers the official ones. or the 3d printed PE replica. note: you don't have to use the special Lok-bolt followers that I made. the stock shape of a PE follower should work like a bolt stop

the DYE Half MAG parts that I made can be found here. (half mag shells, followers) https://cults3d.com/en/design-collections/UntangleART/dye-half-mag-parts

-

materials needed lower mag release: paddle release 1x spring 6mm OD, 0.6mm wire, 12mm long 1x bolt m2 16mm long

L part 1x m3 bolt in a length of 25mm

FGC9 mag release paddle 1x metal pin 4mm OD, 27mm long (a 3d printed part can be used for this)

-

print settings: 0.2 layer hight should be fine. you can use the 8 layer walls and a 40% infill. but personally I moved a bit over to solid prints just to give it more strength in case things go wrong on the field…

movies:

UNW FGC68MKII new lowers for the T15, TMC and Dmag / helix mags for this magfed paintball marker https://www.youtube.com/watch?v=xjbmq-A3C3c https://odysee.com/@UntangleWORKS:a/UNW-FGC68MKII-new-lowers-low:f

FGC68 a small update on the installation of the new lowers for TMC T15 Dmag mags https://www.youtube.com/watch?v=PwSyvEeVHTk https://odysee.com/@UntangleWORKS:a/FGC68-Bolt-update-on-lower:a
