iPhone 13/14 Pro Flexible TPU case

This self-designed flexible case fits perfectly on the Apple iPhone 13 pro (iPhone 14 pro version included as well). It offers precise cutouts and covered buttons that are easy to press.

I had to experiment with the print settings quite a lot on my Ender 3 S1 pro to get a perfect result. Using the following settings, the case came out very lovely with almost no post processing needed.

Filament: Eryone TPU 1.75 mm black Nozzle size: 0.4 mm Layer height: 0.12 mm Initital layer height: 0.24 mm Printing temperature: 195°C Build plate temperature: 55°C Print speed: 20 mm/s Retraction distance: 0.5 mm Retraction speed: 20 mm/s Combing mode: Within infill Coasting: Enabled

Support structures were used just for the cutouts on the left side and bottom of the case. The optional lens cover can be glued to the back side. I did so using "UHU Max Repair power".

I hope you like the design!

P.s. My phone survived a drop on solid ground since I've been using this case, so I can approve that it does its job.

Update 18.03.2023: Slight size adjustments on the iPhone 14 pro model.
