80 tooth GT2 4.9mm stepper shaft

Customized version of https://www.thingiverse.com/thing:16627

Created with Customizer! https://www.thingiverse.com/apps/customizer/run?thing_id=16627

Instructions

Using the following options:

teeth = 80

profile = 6

motor_shaft = 5.2

m3_dia = 3.2

m3_nut_hex = 1

m3_nut_flats = 5.7

m3_nut_depth = 2.7

retainer = 1

retainer_ht = 1.5

idler = 1

idler_ht = 1.5

pulley_t_ht = 12

pulley_b_ht = 8

pulley_b_dia = 20

no_of_nuts = 2

nut_angle = 180

nut_shaft_distance = 1.2

additional_tooth_width = 0.2

additional_tooth_depth = 0

Category: 3D Printer Parts
