TEVO Tarantula - Linear bearings, Y belt tensioner

This mod will require:

- 2x 10mm H6 rods (500mm length)

- 4x SMA SCS 10 UU

- 16x M5 12mm screws with angled head (to mount bearings to base)

- 8x M6 20mm screws to hold down rods

- 4x M6/M5 12mm flat head screws with nuts (to mount table base plate to printed base, you can drill down plate it self to match bearings... I failed with that)

- 1x M5 40mm (up to 60mm) screw with nut head and nut for belt tensioning

- 2x M4 50mm

- Parts that already exist with the printer (M4/M5 screws, T nuts and others)

- Patience :D
