X Belt Shims - Ender 3 V2 Neo

Straightens the belt path, increases accuracy, and reduces belt wear against X gantry.

For Ender 3 V2 Neo , or similar carriages.

This greatly increased the smoothness of the movement on my X axis. It's a must have mod in my opinion.

Remix of Creality/Ender 3 belt shim for X carriage by olov

Updates:

22-03-2022 - Small shape tweaks for better clearance against the belt end clips

Print:

PETG

100% Infill No supports Print with a brim, they will detach from the bed

Installation:

-Loosen the belt tension. -Rotate the piece 90 degrees and place the raised part against the belt pushing it up into the gantry. Twist it in place onto the carriage.

See original images for instalation: https://www.thingiverse.com/thing:3927291
