Blade mSR Tail Fin

This is a replacement tail fin for a Blade mSR RC Helicopter. The stock fin is held by two very fragile clips, and the clips break... The fin is already quite flexible so really there's no need for the clips to be sacrificial, so I made the clamp a lot more sturdy. It holds the 2mm carbon rod quite well.

Part shown in the photo was printed in PETG with 0.1mm layer height and 0.4mm nozzle, and works great.

This was based on the Blade mSR X Tail Fin model, but that model appears to fit a 2.5mm carbon tail boom and is not offset properly to fit the plastic tailrotor mount.

Print Settings

Printer Brand:

Prusa

Printer: i3 MK2.5

Rafts:

No

Supports: No

Resolution:

0.1 or 0.2mm layers

Infill: 100%

Filament: Filaments.ca PETG Gunmetal grey

Category: R/C Vehicles
