Sovol SV06 SV06 Plus accelerometer mount ADXL345 PIS portable input shaper on RPI2040

Hi, I made brackets to test my Sovol SV06 Plus with Portable Input Shaper from FYSETC. This specific one is slightly easier to use - requires only USB-C and flashing firmware to it. There were no brackets available for SV06, so I decided to make one on my own.

All holes are measured for self tapping, no need for heated thread inserts.

Hotbed mount - you need to attach PIS to the bracket, then screw in from the bottom of the bed. With 8mm long screws there is enough clearance for the bed to move freely back and forth. Extruder mount - you CANNOT print with this bracket, this is only for measurement, as while mounted it takes about 2cm of your X, so do not move your extruder over 280mm with the bracket installed! You must unscrew 2 stock screws to the right, temporarily replace them with 2x M3 8mm long screws to attach the whole bracket to the extruder mount, after testing the revert. Do not use screws longer than 9mm (thread length) there as holes aren't through, so longer screws won't hold the bracket properly.

What do you need:

- obviously Portable Input Shaper, similar type (there are 2 versions, with wide and narrow body, both have same holes spacing), based on RPI2040 chip - 4x M3 max 8mm long screws All instructions are available in Klipper docs on how to set up, run it, etc. Documentation of this specific adxl version is available on GitHub: https://github.com/FYSETC/FYSETC-PortableInputShaper

Enjoy!
