DHT22 / AM3202 Switchplate wallmount - 68mm hole

Simple wall mount for a DHT22 / AM3202 type temperature and humidity sensor. Sensor gets mounted with a single M2 - M3 screw and nut while the switchplate gets screwed into the wall using 4 tiny wood screws around M3. The hole this mounts into is a standard 68mm switch hole.

In a hollow drywall without insulation i recommend pressing some insulation behind the plate so the sensors reading isn't influenced by cold air in the walls.

Can be extended to maybe mount a NodeMCU or something on the back as well.

If you need one of my things printed or you want to suggest a modification on a part please drop me a message!

If you print one of my things i would be happy about some feedback and a make!

If you like my things please consider supporting my caffeine addiction!

Print instructions

Textured print bed will make the front look better. PETG is recommended.
