Nozzle cleaner and purge bucket for the BLV MGN Cube

It is based on an idea from @TownDrunk . Thanks to him !

This silicone wiper is better than wire brushes because it does not harm your nozzle. The removable bucket gather your filament purge and is easily removable.

You can put some oil on the silicon pieces so the purge won't stick.

There are 3 places for silicon sheet holders, i only use 2. I used a silicon straw that i've cut to the dimension (template is in the files). I found using a silicon straw is good because, as it is curved, the wipe is more efficient than traditional and expensive silicon sheets.

There is several silicon sheet holder to adapt the silicon sheet width : 1.4mm, 1.6mm, 1.8mm. If you need anything different, just ask !

I included the macros i use in klipper, just in case. These macro are a WIP, so take care.

You'll need :

2 M3 8mm screws

2 M5 8mmscrews and 2 M5 T-nuts

4 6x2mm magnets

2 4x1.5mm magnets (optional but i found it's more sturdy with them)
