Corsair Scimitar Scroll Wheel

A replacement scroll wheel for the Corsair Scimitar pro. If scrolling does not work on your corsair scimitar pro and the wheel moves without resistance, this might be due to a broken pin on your scroll wheel. This replacement part can restore your scrolling capabilities. Remember that opening your mouse will void its warranty.

Update : Split the mouse wheel into two parts to make it easier to install. Made the smaller end of the pin longer and a bit thicker.

The pin might need some sanding on the underside, so test if it fits inside the wheel beforehand. Move the wheel into place and slide the pin in from the side. The smaller end of the pin is a bit to long, so just cut it off once its installed.

Print instructions

Printed with supports on buildplate only at 0.15mm layer height in Prusament PLA galaxy silver. I would recommend using a raft for the pin.

The wheel is 8mm deep and 27.4mm in diameter. The pin is 34mm long and 6mm in diameter at its thickest point.
