Ratrig V-Core BTT TFT50 2.0 Mount

Mounting arms to be used in conjunction with StvnLntz BTT TFT50 v2.0 Case.

https://www.printables.com/model/198864-btt-tft50-v20-casehousing-mount-revision-2

I added the arms off of the panel holders used for the enclosure 2.0 so it is compatible with or without the enclosure. This model leaves room to reach brightness wheel and switch when the enclosure panel is off and leaves about 2mm of clearance to table top.

BOM:

1 - Mount Left

1 - Mount Right

4 - M2.5x6 or M2.5x8 to mount arms through back panel of housing into display

2 - M6x12 Socket Cap screws

2 - M6 T-Nuts

Printed out of ASA with 4 perimeters, .4mm nozzle at .2mm layer height and 40% infill.
