Thunderbolt Solar Panel Clip

Mounting clip for Thunderbolt 100w Solar Panel. Snug snap-on fit with flanged countersunk screw hole for wood/drywall/deck screws.

Print Settings

Printer Brand:

AnkerMake

Printer: AnkerMake M5

Rafts:

No

Supports: No

Resolution:

.3

Infill: 100

Filament: Sunlu PETG Red

Notes:

Printed on it's side for no supports.

Post-Printing ============= Insert bottom lip first and push/snap top into frame.

How I Designed This

Measured frame and created a 2D clip on/wrap around design in Corel Draw, then imported into Tinkercad to extrude and create the STL.

Category: Electronics
