Single tape roll holder - Wall mounted (Double side tape)

Сведения о модели

Площадка
Printables
Цена
Бесплатно
Лицензия
CC-BY-NC-SA
Только некоммерческое использование с указанием автора; переделки — под той же лицензией.
Форматы
STEPF3D
  • 4 Лайки
  • 44 Загрузки
  • 0 Напечатали
  • 1 Комментарии
  • 194 Просмотры

Автор:Bram

Опубликована

Описание

I really liked the design of the original wall mounted tape holder. It could be printed without supports and the end of the wall mount has some nice geometry. That's the part that I remixed.

In the files attached you'll find the STP of the file I made for my roll of tape. However, I also added the Fusion360 file which is parametric. You can change the dimensions of your own roll of tape to create the desired wall mount. The dimensions are:

- Tape_Outer_Diameter - Tape_Core_Diameter - Tape_Width I decided to go for double sided tape to attach my wall mount, but it will be very easy to add screw holes to this design as well.

I printed this with 4 perimeters and 4 solid top and bottom layers. I used 15% gyroid infill and so far it holds up fine.

I hope it is useful to some of you!
