IEC 62196 Type 2 Design Template

IEC 62196 Type 2 notes

- The most complete specs I know are published by Phoenix Contact, who also offer CAD files for download:

- The nominal outer diameter of the plug's shroud is 63 mm and the height is 56 mm. The radius of the corners, I haven't found documented anywhere.

- https://www.phoenixcontact.com/en-gb/products/ac-charging-cable-ev-t2g3pc-3ac20a-10m25esye11-1247584

- The nominal outer diameter of the charging socket is 65 mm and the height is 57.8 mm. The nominal rounding radius at the corners is 16.8 mm.

- https://www.phoenixcontact.com/en-gb/products/infrastructure-charging-socket-set-ev-t2m3so12-4p-bl-set-1268355
