Y axis tensioner for Ender3pro and ender3v2

This is useful for hotend mounts that moves the hotend forward (like all of my designs for top mounted hotends, and likely many other), which usually lead to lost printable space, this gains 10mm back, for the full 235mm in Y

But does require a longer than stock belt (about 20mm more)

There are many variation of each piece, read the file names to pick what works best for you and the hardware you have on hand.

This is based on ender3v2 tensioner, so I made it so that the stock inner sled remains compatible and can be used

The front wheel is totally optional you can use the stock one, or other design found around.

No print support.

Ender3v2 has screw on the front so you can use model without the side tabs and reuse the stock screws. On ender3pro the front doesn't have those tapped, so use the model with side tabs instead, you might have side holes, otherwise use t-nuts

------
