BOX! for Cooler Master Qube 500

BOX!

is organizer for computer case Qube 500 from Cooler master. It serves as storage for things used on the computer. BOX! it is attached to the Qube500 using 3 Cooler Master clips. It is designed to suit every user. There is a hole on the top of the organizer that you can use to enrich the organizer with other components. Just create a model that will have a Gem mini holder by Cooler Master.

If you want BOX! to be more colorful, you can use side accessories that enrich your organizer with interesting shapes and colors! Of course it is only optional.

Also, the front logo is up to you if you fill it in or just leave it as it is.

Printing

In order to use as little material as possible during printing, this model is designed so that it needs as few supports as possible. Therefore follow the placement of the model as shown in the pictures! But everything is already prepared as it should be. :)

There are many parts in the model that do not need supports because they are at a 45 angle. However, some supports are needed, so set the support overhang angle in your slicer to 46 degrees. Don't worry, your printer will definitely handle it. :)

Assembly

Assembly is very simple. You slide the front side of the shelves onto the rail starting from bottom of base. Then you just slide it in clockwise. The picture shows how to do it and two points where you need to use a bit of force. When it clicks at these points, it's all done. Then it's up to you to add accessories. If so, print them out and then stick with glue them in the appropriate place.

Thank you for your interest in my model and I wish you good luck with the printing.
