Little Boy S - Tiny Mini ITX case

Check out the full build video here explaining assembly in detail:

This case uses less than 700 grams of filament in total and requires a print surface of 230x230mm or bigger.

** A front panel version without the logo is also added in case you'd like the case exterior to be only honeycomb or other pattern of your choice.

The case in the video/pictures uses no top and bottom layers on all panels, only perimeters and infill.

- Infill type used: Honeycomb (in PrusaSlicer)

- Infill percentage for same look: 20%

- Filament type used: PETG (Black and White)

Dimensions of this case:

Length: 217,5mm / Width 164mm / Height 227mm

As an Amazon Associate I earn from qualifying purchases. All product links below are Amazon affiliate links.

- What's required to build this case?

1 KG 3D printer filament (PETG recommended)

Hot glue gun + glue (recommended for the magnets)

5x - M3 threaded inserts

5x - M3x10mm machine screws

8x - 8*3mm Neodymium magnets

12mm Power Button (Pre-wired)

- PC components I used to build this case:

ASUS ROG B450i ITX motherboard (AM4 socket, same model not available, but here are some options): https://amzn.to/46vQhrp

Corsair SF450 SFX power supply: https://amzn.to/3QgJz2H

Gigabyte 1660 Super ITX (not available new anymore, this one is similar size but better): https://amzn.to/45AmuMK

Kingston A2000 M.2 SSD 250GB + 1TB: https://amzn.to/40brCWR

If you'd like to see this case from a different perspective, feel free to check out this video review from “Mike's Unboxing, reviews and how to”!
