cyclone dust collector

Cyclone Dust Collector

The Dust collector main body fits perfect on a Prusa MK3 Printbed.

Update 03.03.2025:

- Os Vac Neo M32 Intake and Outlet Adapter

Update 25.01.2025:

- Os Vac Neo F32 Intake and Outlet Adapter

- 35mm, and 38mm outer diameter hose direct Thread adapte

spare part list:

- PLA/PETG/ASA Filament

- TPU Filament (sealing)

- M5x12 Screw 6X

- M5 Heat insert 6X M5x5,8mm

- M5 or wood screws to conntct the Dust collector with the barrel 5x

I recommend a 0.6 or 0.8 bigger Nozzle to print the main body to reduce print time.

Contact me if you need some special adapters.

you find some dummy adapters below to create your own connectors

happy printing :)
