Hyte Y60 3x120mm Fan Adapter/Shroud

An adapter to fit three 120mm fans on the “front” side of your Hyte Y60 case!

20 fan screws and 3x120mm fans are needed for this modification. 4x screws per fan to hold them onto the adapter/shroud. 8x screws to mount the adapter/shrouds to the case.

Instructions

You will need to print both the fan shroud top and bottom, as well as 8x the “screw thingie” pieces PLA is fine.

Screw the fans into the adapter/shroud with them inside the case already. There's not a whole lot of room for play here. Once the fans are screwed into the adapter/shroud in the case, you will use the model “Screw Thingies” to screw the adapter/fan unit into the case using the 140mm fan holes.

You can trim the back of your case for better airflow if you would like, but I did not and my case cooling doesn't seem to mind.
