BoboVR Battery Dock Replacement

This replaces the BOBOVR battery dock and allows you to use an external power bank in its place while retaining the “hot swap” capabilities. I went with the INUI BI-B61.

If you don't have a compatible headstrap for the full replacement check out this option.

Materials Needed

- 10x3mm Neodymium Magnets x8 - 1-1.5ft USB C cable (preferably right angle for quest side) - INUI B1-B61 (or another power bank but model is designed for this one) Print in orientation shown in pictures. Model in pictures printed in eSun PLA+. Magnets were press fit without the need for glue and holes have a tolerance of 0.1mm.

Print parameters:

0.2mm layer height

3 walls

10% infill (I used gyroid)

Supports needed
