Creality Ender 3 V3 KE Slicer profiles for PrusaSlicer & Cura

Please give it a 💖 if you like it 🥰

Edit 2024-07-28 :

- Flavor updated Edit 2024-07-13 :

- Added a “Quality Profile” - Added the thumbnails to preview models on the printer

👉 Link to my Ender 3 V3 SE Profile

👉 Link to my Ender 3 V3 Profile

👉 My other Slicer Profiles & Models

Please leave a comment if you have any possible improvements to make to these profiles 😉👍

How import profiles?

In PrusaSlicer

Here is the link on how to do it: https://help.prusa3d.com/article/how-to-import-and-export-custom-profiles-in-prusaslicer_382766

In Cura

- 🪧 Don't use the profiles listed in Cura for 'Ender 3 V3 KE" 👉 Create a new printer instead 1 - “Creality Ender 3 V3 KE”

- Set the printer parameters 1 - X (Width): 220

2- Y (Depth): 220

3 - Z (Height) : 250

4 - Start Gcode

M220 S100 ; Reset Feedrate M221 S100 ; Reset Flowrate

G28 ; Home

G92 E0 ; Reset Extruder G1 Z2.0 F3000 ; Move Z Axis up G1 X-2.0 Y20 Z0.28 F5000.0 ; Move to start position M109 S{material_print_temperature_layer_0} G1 X-2.0 Y145.0 Z0.28 F1500.0 E15 ; Draw the first line G1 X-1.7 Y145.0 Z0.28 F5000.0 ; Move to side a little G1 X-1.7 Y20 Z0.28 F1500.0 E30 ; Draw the second line G92 E0 ; Reset Extruder G1 E-1.0000 F1800 ; Retract a bit G1 Z2.0 F3000 ; Move Z Axis up G1 E0.0000 F1800 5 - End Gcode

G91 ; Relative positionning G1 E-2 F2700 ; Retract a bit G1 E-2 Z0.2 F2400 ; Retract and raise Z G1 X5 Y5 F3000 ; Wipe out G1 Z5 ; Raise Z more G90 ; Absolute positionning

G1 X2 Y218 F3000 ; Present print M106 S0 ; Turn-off fan M104 S0 ; Turn-off hotend M140 S0 ; Turn-off bed

M84 X Y E ; Disable all steppers but Z 1 - Compatible material diameter: 1.75

- Unzip the *-KaminoKGY-Cura.zip file and import the profile file (Manage profiles > Import)
