Airbus A320 FCU Panel

Dimensionally accurate three layer panel. Designed to be CNC routed from 3mm cast acrylic, but can be 3D printed if backlighting is not required. Top panel 3mm Opal. Middle panel 3mm frosted clear. Bottom panel 3mm clear. Designed to be either glued or screwed together after painting and engraving.

Designed to use the excellent Kav Simulations custom FCU LCD Units which isavailable from their web site:

https://jak-kav.co.uk/products/a3xx-fcu-lcd-unit

And designed to work with my other models, available here on Printables:

https://www.printables.com/model/441903-airbus-a320-fcu-speed-knob

https://www.printables.com/model/441909-airbus-a320-fcu-heading-knob

https://www.printables.com/model/494628-airbus-a320-fcu-alt-knob

https://www.printables.com/model/438644-airbus-a320-fcu-vertical-speed-knob

Airbus A320 FCU Push Pull mechanism by MANTOGA | Download free STL model | Printables.com

Airbus A320 FCU Korry style Switch by MANTOGA | Download free STL model | Printables.com

Airbus A320 EFIS Korry style Switch by MANTOGA | Download free STL model | Printables.com

Please note that push-pull mechanism doesn't currently include a switch for 100 /1000 selector. This will be added.

Push Switches are available from AliExpress:

https://www.aliexpress.com/item/1005004542307924.html?spm=a2g0o.productlist.main.31.a34e6gmD6gmDBK&algo_pvid=faa0f127-b7ba-4759-80d4-4e61c7ae9396&algo_exp_id=faa0f127-b7ba-4759-80d4-4e61c7ae9396-15&pdp_npi=4%40dis%21GBP%213.64%212.91%21%21%214.50%21%21%40210387a117041863235611615e18d5%2112000029542215212%21sea%21UK%214240429356%21&curPageLogUid=xGP0zOuhbRXT
