"Der Forklifter 2.0" - Fan Duct for Geeetech A10M and A20M dual colour printers

(copied from thingiverse, but keep in mind the changes i made)

Because the cooling on my A10M and A20M was not quite convincing, I designed this part with following concepts in my mind:

More silent 40x10 or 40x20 Fan instead of the two 30mm fans for the hotend Better cooling with a radial 5015 Fan To see better whats printing Customisable The BLTouch has following X and Y offsets: X= -43 mm Y= -26mm

Check also the spacers so far you need some https://www.thingiverse.com/thing:3556404

What you'll need:

Extra parts: 1x Axial 40x10 or 40x20 (recommended) for the hotend 1x Radial 5015 for the Fan Duct / Part cooling fan

Printed Parts: -Base -Front -PCF -BLT Mount (optional) 1x recommended Hotend PCB Mount: https://www.thingiverse.com/thing:3195894

Mounting bits: 4xM2x12 for carriage M3 Screws

- 4x 25mm - 2x 10mm - 3x 15mm(for BLT) - 2x - 4x 15 /25m for the Fan - 2x M3 nuts for the Partcoolingfan I highly recommend a silicon sock on the hotend, otherwise, you will get min Temp Errors over 30% of the Partcoolingfan
