Elastic Football

All parts are printed without support, Z=0,30mm. For shooting mehanizm you need 10x standard everyday elastic rubbers. It is constructed that you can replace the elastic if it become weak. Print it with PLA or PETG. I suggest that you print parts with same color together.

All the parts you need to print are:

HOW TO PRINT?

2x HALF Field (Green) (Print with brim 10)

(suggest to print it 1 by 1)

1x Joiner (White)

2x Goal (White)

2x Shield L (Black)

2x Shield R (Black)

2x Counter Holder L (Black)

2x Counter Holder R (Black)

2x Stick 95 (Black)

10x FIX Player (Grey)

10x Player Holder (Grey)

2x FIX Goalkeeper (Grey)

2x Mover Goalkeeper (Grey)

6x Player (yellow) (100% infill)

5x Poen (yellow)

6x Player (orange) (100% infill)

5x Poen (orange)

Ball 15 (white)

(print 2x half(cut with Prusaslicer)

variable layer hight for top layers 0,07

Glue together to get perfect ball

HOW TO BUILD?

- Join together 2x HALF Field with Joiner

2. Put together FIX Goalkeeper (Grey) and Mover Goalkeeper (Grey)

3. Put it in the HALF Field (do it on both sides)

4. Build player mechanism 1x FIX Player (Grey) + 1x Player Holder + (Grey) 1x elastic

Put the middle part of elastic around the Player holder from all 4 sides. I used elastics with diameter 40mm. Please be carefull, it can be dangerous if you fail.

A little bit tricky, but do this 10 times :), last one is easy when you learn.

Be precise, elastic should be strait and the Player Holder exact in the center of the circle.

Thanks for GIF tutorial How to do this to 3Dmensional.de (just click on his picture in a comment)

https://www.printables.com/model/74135-elastic-football/comments/984366#preview-comment

5.Put all 10 mechanisms to the prepared holes on HALF Field

6. Prepare Shields and mount them

7. Prepare Goals and mount them

Cut the pillar

8. Prepare and mount the counters (it is one time only build, cant demount!)

Put Stick 95 (Black) into Counter Holder L (Black), put on it 5x Poen (yellow) and close forewer with Counter Holder R (Black).
