FBG6 BIQU Microprobe mount

To mount BIQU Microprobe to your Flying Bear Ghost 6 print this back cover and install it in place of the original.

Print it from some heat resistant filament such as ABS. It is designed to be printed in a vertical orientation to make small clips that attach to the main body stronger. You'll need to add supports to the areas highlighted in blue in the picture. Other horizontal elements print fine with bridges.

To assemble everything you'll need following hardware:

- two M3 heat inserts; - two M2,5x8 screws and two M2,5 nuts from the Microprobe kit; Probe offsets from the nozzle: X=0, Y=40, Z=0,8…1,0 (you must calibrate z_offset yourself).
