ESP32-WROOM-32U Casing

ESP32-WROOM-32U Based WiFi Repeater

- Utilizes the ESP32-WROOM-32U module for powerful WiFi repeating capabilities. - Enhanced signal strength with an external antenna (IPEX connector) for optimal performance. - Firmware based on ESP32 NAT Router Extended, accessible at: - ESP32 NAT Router Extended GitHub Accessible Design

- Thoughtfully designed casing with openings for easy access to: - ESP32 pins for customization and expansion. - Power indicator LED for monitoring device status. - Two buttons for quick configuration and control. - USB connector for convenient power supply. Secure Closure

- Snap-fit connections ensure a secure closure of the casing, keeping components protected. Optimized Ventilation

- Ventilation holes on the casing lid ensure efficient cooling for the WiFi module during operation. Materials

- ESP32-WROOM-32U Board: Purchase Link - Utilizes the ESP32-WROOM-32U module for WiFi repeater functionality. - 2.4GHz WiFi Antenna: Purchase Link - Enhances signal reception for improved WiFi performance. 3D Printing

- Precise design for perfect fit of components. - Ensure your 3D printer is well-calibrated. - Printed with a 0.4mm nozzle, 0.20mm layer height, 4 perimeters, 4 bottom layers, 6 top layers. No support needed. Adjust according to your configuration.
