Flying Bear Ghost 6 TZ V2 hotend adapter

The TZ V2 is an hybrid clone of a V6 cooler and Bambu lab X1C heating block available for cheap on AliExpress.

This adapter lets you use this hotend and replace the stock hotend, giving you a lot more quality and flow speed.

Print it at 0.12mm layer height (0.4mm nozzle), 100% infill, ABS (to warranty heat resistance).

You'll need:

- 4 M2.5x10mm hex button head screws (to join the adapter to the hotend) - 2 M3x10mm hex socket head screws (to join the adapter to the printing head) - 2 M3 nuts if you print the nuts version - 2 M3 diameter 4.2mm length 3mm brass insert nuts you need to insert them with a soldering iron
