V0 Dragon Burner ADXL345 accelerometer brace

Сведения о модели

Площадка
Printables
Цена
Бесплатно
Лицензия
CC-BY-NC
Можно печатать и изменять для себя с указанием автора; продавать модель и отпечатки нельзя.
Форматы
STL
  • 24 Лайки
  • 163 Загрузки
  • 0 Напечатали
  • 1 Комментарии
  • 954 Просмотры

Автор:seb3d

Опубликована

Описание

This replaces the “brace” part of the Dragon Burner toolhead ( https://github.com/chirpy2605/voron/tree/main/V0/Dragon_Burner ) for the Voron v0.2. You can mount an ADXL345 accelerometer to it for measuring resonances. The brace needs to be replaced again after calibration, otherwise it can collide with the z screw. The mount is pretty close to the nozzle so it should result in pretty precise measurements. I tested it with the standard cowl and a Dragon SF Hotend.

BOM:

2x 10mm M3 screws for the brace

2x 6mm M3 screws for the accelerometer

2x M3 4mm heated inserts (slighty longer might also work)
