Anet A8 E3D Tronxy

The other holder for the Tronxy Sensor was to short, so I made a longer one. I have designed it with Autodesk Inventor 2018.

My Marlin Offset Settings:

define X_PROBE_OFFSET_FROM_EXTRUDER -28

define Y_PROBE_OFFSET_FROM_EXTRUDER 5

define Z_PROBE_OFFSET_FROM_EXTRUDER 0

define X_MIN_POS -18

define Y_MIN_POS -10

define Z_MIN_POS 0

define X_MAX_POS 240

define Y_MAX_POS 230

define Z_MAX_POS 240

UPDATE

Added a version with long holes for m3 nuts.

Print Settings

Printer:

Anet A8

Rafts: Doesn't Matter

Supports:

Doesn't Matter

Resolution: 0,2

Infill:

40

Notes:

Printed with ABS

Category: 3D Printer Parts
