90 Degree Bracket for 2020 Extrusion for Ender-5, Pro, Plus

This is a remix of:

https://www.thingiverse.com/thing:3644062

I liked the design of the original bracket, but wanted to try and make it a little smaller. This design is about 50% scale of the larger bracket. Included is both a 2 bolt and 4 bolt version. Bolt holes are for a 5mm x 12mm Button Head hex bolt to be used with matching T-nuts. Two bolts should hold just fine, but for added security, I also included a 4 bolt version.

Print Settings

Printer Brand:

Creality

Printer: Ender 5

Rafts:

No

Supports: No

Resolution:

.2

Infill: 15% Gyroid

Filament:

Duramic3D PLA+ White

Category: 3D Printer Parts
