Rear Mount for Prusa XL Filament Sensor - Remix

When trying to use the original model from kez I faced the problem that my M3 nuts where to small for the internal openings. This caused them to spin, when I tried to tighten the screws. I created this remix with tighter tolerances to fix this issue.

This model has openings with a side to side distance of 5,6 mm while the original model was 6.2 mm. I used M3 nuts with a width of 5,4 mm, which result in a nice snug fit.

The original model contains a great explanation on how to mount this, please check on that for detailed instructions.

I routed the bowden tubes in reverse order through the filament sensor (extruders to the top), which seem to work just as fine as using them in the intended direction.

This model is part of my Prusa XL Drybox project .
