Center drill for Honeycomb storage wall

This is a guide for drilling a hole in the center of a empty slot for the hex grid to attach it to a wall for anchors, screws, etc.

because if your anything like me, i cant drill straight or mark center very well.

This includes metric sizes (25 total) from 1mm-13mm and standard sizes (16 total) from 1/16"-½".

I printed mine in PLA, which i do not recommend because it was such a tight fit, I would recommend PETG or better if you can. Their is no locking or snapping, but the tolerances are very tight so you might have trouble inserting/removing it from the slot. I've noticed that is is much easier grabbing it with channel-locks and pulling it out since I used PLA.

You can scale it up or down if you need the length smaller or longer, but by default it should stick out about 10mm when flush with the back.

recommended print settings:

PETG or better

3+wall perimeters

temp: highest your filament can do reliably for strength, or lowest for accuracy.

This was made in blender, so i apologize for not having a .STEP file available.

some of my center drilling skill reviews:

"Watching them try to drill a straight hole is like seeing a one-legged man in a butt-kickin' contest. You can't help but admire the effort, but you know it's a lost cause from the start.'"

-Bubba Jenkins

"They're like someone trying to thread a needle with a rope. The ambition is admirable, but the execution? Well, let's just say it leaves much to be desired."

-Patty Mae

"Their approach to drilling a straight hole is as effective as a screen door on a submarine."

-Earl Dixon

“pretty sure I can drill more center than he could.”

-Stevie Wonder

“His accuracy? worst I've ever seen.”

-Stormtrooper TK-4221
