Xiaomi Scooter M365 Wall Mount

After using @Ehome_474960 “ M365 Wall Mount” for a year before it failed, I decided to make my own inspired design to fix some issues I've had with it while also improving the overall functionality and structural integrity.

- Split it into two parts, baseplate and arm. This way the arm can be printed optimally (layer lines in the direction of the arm) for much better durability. - Arm attachment to the baseplate has been reinforced with: - Walls holding the arm in place. - Ribs for distributing forces over a bigger area. - 4 screws holding them together. - Adhesive is recommended as well for extra strength. - Reduced arm height: - Puts less pressure on the breaking cable (the previous design caused some damage to it for me). - More room to place/remove the charger from its holder. - Reduced arm length for a bit more stiffness and tighter fit against the wall for the scooter. - Redesigned holder for charger: - Easier to place and remove the charger if needed. - Still holds it in place if cables are pulled. - Takes less space, making the whole thing look a bit neater. - And a lot of smaller details for extra strength, less material use and prettier design. Compatible screw holes against wall with @Ehome_474960 version.

Editable files f3d (fusion) and step are available.
