Prusa Enclosure ESP32 Camera Support

Сведения о модели

Площадка
Printables
Цена
Бесплатно
Лицензия
CC-BY-NC
Можно печатать и изменять для себя с указанием автора; продавать модель и отпечатки нельзя.
Форматы
STL
  • 69 Лайки
  • 264 Загрузки
  • 17 Напечатали
  • 33 Комментарии
  • 1 717 Просмотры

Автор:pachek

Опубликована

Описание

update: base file version 1.1 to make compatible with USB-C plugs sizes

Support for ESP32 cam to the prusa enclosure corner. Considering the 65º FOV of the ESP32 stock camera it will cover the entire printing surface and a bit more:

It needs a couple of M3 bolts and nuts to attach to the enclosure existing holes:

the camera is secured just by a clip:

Print on the given orientation, no supports are required.
