Elegoo Neptune 3 / 3 Pro / 3 Plus / 3 Max Filament guide

Сведения о модели

Площадка
Printables
Цена
Бесплатно
Лицензия
CC0
Общественное достояние: можно печатать, изменять и продавать без указания автора.
Форматы
STL
  • 21 Лайки
  • 84 Загрузки
  • 0 Напечатали
  • 0 Комментарии
  • 1 114 Просмотры

Автор:Aiddy81

Опубликована

Описание

I printed this mod (https://www.printables.com/model/566621-elegoo-neptune-3-proplusmax-filament-run-out-sensor) to move the filament sensor above the extruder, as my roll sits in a dryer above and behind the printer I needed something to make a smoother path for the filament as it's pulled, so I quickly designed this.

Requires:

1 x m3 16mm 1 x m4 20mm (for the bearing) 1 x 608-2RS bearing

The m3 screw is to scew it to the filament holder, as it was super quick I didn't measure up the original screw used for the sensor, I may update this at a later date once I get some time to use the original m3 screw.
