Filametrix depressor mount for Ender 3

This depressor arm for The filametrix filament cutter mounts to the stock Ender 3 x-axis end-stop cover. Allows the uses of the Filametrix on an Ender 3.

X-Endstop must be repositioned to be a positive stop. (right side)

Required Items:

- 2x M3 heat set inserts. (standard Voron 4mm x 5mmOD) - 1x M3x16 BHCS for depressor arm - 1x M3 nut use to secure BHCS(jam nut) - 1x M3x8 FHCS - 4x M3x45 SHCS for mounting to X-Axis cover Insert two heat-set inserts into the depressor arm. These must be flush or just below the surface.

Thread M3 nut onto BHCS and insert depressor arm.

Secure depressor arm to mount using FHCS

Attach mount to X-Axis end-stop cover using M3x45 SHCS

Adjust BHCS to fully actuate filament cutter just short of maximum negative x-axis travel and lock in place with jam nut.
