Duel UHP-500 DIN Rail Mount

Mount 2 UHP-500 PSUs within the same width of an LRS-200.

Required BOM:

2 M3x16 cap head screws

4 M3x25 cap head screws

2 M3 5x4mm heatset inserts (Voron spec)

4 M3 square nuts

Instructions:

Install heatset insert into part A

Install 2x square nuts into each center block (part B)

Flex part A over DIN rail

Install PSUs

Secure part B with M3x16 screw into heatset insert

Secure PSU with 2x M3x25 screws at each end.
