Fractal R5 PSU Shroud

Features

- A decorative power supply shroud for the Fractal Design R5, but will likely fit several mid-tower-sized cases with removable hard drive trays

- 410mm long, 94mm tall, 170mm wide

- Includes a 120/140mm fan mount for GPU cooling, cutouts for cable routing, and a sloped design for better front airflow Printing Guidelines

- Layer height: 0.2/0.3mm Supports: No Brim: Yes (front, mid, rear), No (fangrille) Walls: 2+ Infill: 10%+ I suggest printing everything in the orientation the model comes in, to prevent excessive overhangs or build plate artifacts from being visible.

Assembly

- Remove all brims and glue the rear, mid, and front together - the rear and mid slide together neatly, then the front presses on afterwards.

- Once set, glue the fan grille on. This may be a tight fit, so you might need to sand the edges down slightly.

- Install a fan (if you want), remove the Fractal's bottom HDD cage (you can keep the top one) then slip the whole assembly into your case - the very rear of the shroud should slip between the PSU and the PCI-E slots.

- Cable route as needed, and you're done.
