Heltec LoRa 32 V3 HT Slim Cases

Update 24 April 2025:

Added a 3k version with internal antenna space and no SMA.

Update 30 July 2024:

Added desk mounts and Baofeng clips that take M2.5 nuts.

Commercial Use and Attribution Notice:

Alley Chat HT Slim © 2024 by Alley Cat and Majestic AV, LLC. is licensed under CC BY-SA 4.0 .

Commercial use of this design, including promotional use, selling, and reselling to other businesses for sale, is permitted under the following conditions: Prior to any commercial exploitation, you must contact Alley Cat or MajesticAV, LLC to ensure proper attribution. This requirement extends to any sharing, distribution, or creation of derivative works, including manually crafted designs that emulate this design. Proper attribution must be clearly stated in all instances of use. For official contact methods and further information, visit Majestic AV, LLC - Alley Cat . Any other sources are unauthorized and should not be used for commercial or licensing inquiries.

Disclosure: Some links on this page may be Amazon affiliate links. If you make a purchase through them, I may earn a small commission — at no extra cost to you. I only recommend gear I trust and use myself. Thanks for your support!

Suggested Print Settings:

Material: PLA+ or PETG Nozzle: 0.4mm Extrusion Width 0.4mm Layer Height: 0.2mm Perimeters: 3 Infill: 0% Top/Bottom Layers: 5 Support Material: None

3D Printing Disclaimer:

Thank you for downloading my CAD design! I want to assure you that extensive testing and iteration went into creating this design. However, please keep in mind that 3D printing involves a wide range of variables, including different types of filament, printer settings, and calibration levels. These factors can significantly impact the final print.

Before concluding that the design is flawed, I encourage you to:

• Check your printer calibration: Ensure your printer is properly calibrated. Especially filament shrinkage.

• Adjust print settings: Try changing the print settings to achieve better results.

• Resize the model: Scaling the model up or down slightly may resolve fit issues.

Remember, these are development boards and sometimes have very fragile parts. If you encounter any issues or need assistance, please feel free to reach out to me. I am here to help and can provide guidance to achieve the best results. Claiming a design is bad without considering these variables does a disservice to the community and may discourage others from trying a design that could work perfectly with minor adjustments.

Thank you for your understanding and cooperation. Happy printing!

Description:

Custom case for the Heltec LoRa 32 V3. No hardware needed unless you want to use the Baofeng style clip which requires M2.5 nuts or heat set inserts and M2.5x5mm screws. Here are links to the parts I used:

Heltec LoRa32 V3 from MakerHawk or MakerFocus

2000mAh MakerNova LiPo Direct / Amazon

3000mAh MakerNova LiPo Direct / Amazon

Internal Antenna

Perfect Fit Folding Antenna

17cm SMA Antenna Direct / Amazon

Will not fit an antenna with bigger than 11mm base

Right Angle SMA

Baofeng Belt Clip

Generic Belt Clip

Heat Set Inserts

I personally do not sell anything , but you can order these cases already printed from a couple of sellers online. I am not affiliated with these stores and do not make any money from them.

Video:
