Macropad with rotary encoder

WPad Simple macropad with rotary encoder. This is my old project that I made 2 years ago to learn keyboard desing and play around with qmk firmware.

functionality WPad offers 7 keys and rotary encoder, default keymap works mainly as a spotify and sound control device. It is made with pro micro in mind and you might want to use supports on the bottom side because of the screws I used (M5 Cap head screws). You might wanna print this EC11 to switch adapter

https://www.thingiverse.com/thing:3770166

BOM

- 7x Diodes - 6x Cherry mx style switches - 1x EC11 rotary encoder - 1x Pro micro - 4x M5 8mm Cap head screws - 6x Cherry mx compatible keycaps - some wires, hot glue and of course 3D printer with your favourite filament Pin assigment

Row Pin Col Pin Encoder Pin

0 B6 0 E6 A B4

1 B2 1 D7 B B5

2 B3 2 C6

QMK flashing and editing keymap

Firmware and all other files can be found on my github

https://github.com/kubek344/Wpad

And if you don't know how to start with qmk then I recommend you to read this newbs guide

https://docs.qmk.fm/#/newbs
