VW T5 Transporter / Multivan Bus Kit Card

Summary This is a model of a VW T5 Multivan (Facelift) in a kit card style. Some characteristic details can be discovered. After printing, the model can be assembled with the help of integrated connectors. The wheels can be turned, but the car will not roll.

Versions The complete set is available in a STL file for a one-color print. There is a 3MF-file with predefined colors intended for users of AMS or MMU. Otherwise, the body, tires and rims and the tires must be printed separately.

Print Print with 0.15 layer hight or lower to bring up the details. No supports are needed. Use 3 perimeters and 10% infill.

Post processing The small struts can be removed really quickly and cleanly using a side cutter.

Assembly The kit is easy to assemble. All parts fit together very well. Use some grease for the hole in the rim so that the wheel turns more easily. If a part should be loose, superglue can be used.

Dimensions The fully assembled model has the following dimensions Height: 66.4mm Depth: 172mm Width: 77.5mm (including side mirrors)

The complete kit card has the following dimensions when printed Height: 56mm Depth: 183mm Width: 121mm Scaling will work in a low range due to the tolerances.

Other models I will also try to publish other car models. Stay tuned!

I hope you had as much fun printing and assembling it as I did :-)
