Carbon Camera TriPod 📸🦾

I designed this tripod because I had some leftover carbon tubes from another project. 🛠

There are two versions tailored for different carbon tube sizes:

For tubes with 26mm outer diameter and 22mm inner diameter 📏

For tubes with 25mm outer diameter and 23mm inner diameter 📐

The carbon tubes are typically 320mm long , but you can adjust the length to your preference. ✂

Printed parts are made from PETG or PCTG , but other materials can work too— avoid PLA for durability reasons! 🚫🧪

For extra strength, I used M5 threaded inserts for screws and 3/8" to 1/4" thread adapters for cameras, ensuring long-lasting and secure connections. 🔩

The ball head model used is "Tripod Ball Head" by zx82, but you can use other compatible ball heads as well. 🎯

Material List 📦:

3x Ruthex M5S threaded inserts

1x 3/8" to 1/4" thread adapter

3x M5x35 screws

3x Carbon tubes (320mm length, 25mm or 26mm diameter) [Link to 25mm Carbon Tubes]

Printed Parts 🖨:

3x Foot (25mm or 26mm)

3x Foot ring (optional, aesthetic)

3x Joint (25mm or 26mm)

1x Tripod center

3x Screw handle

3x Screw handle plug

Assembly 🔧:

Print all required parts.

Foot rings are optional and mainly for looks.

Cut carbon tubes to your desired length. ⚠ Warning: Carbon dust is toxic — wear respiratory protection & gloves when cutting! 😷🧤

Glue feet and joints into the tubes using epoxy glue.

Glue screws into screw handles, close with plugs using epoxy.

Insert the M5 threaded inserts into the designated holes.

Screw the 3/8" to 1/4" adapter into the tripod center.

Attach joints to the tripod center and secure with M5 screws.

Mount your preferred ball head.

Print Settings 🖨:

Material: PETG, PCTG, ABS, PC, PA (No PLA!)

Infill: 50%

Walls: minimum 2

Support: Only needed for foot and joint parts

Feel free to like and share your makes! 😄✨
