Playstation/ Xbox LED Light

UPDATE 01/08/2023

- redesigned ps_logo_resin & ps_logo_socket due to some 3D Model issues with the 3DCAD-Files - reduced the file size of ps_logo_resin - new names: - ps_logo_resin_v2 - ps_logo_socket_v2 ----------------------------------------------------------------------------------------------------------------

Hello Guys!

This is my version of a Logo for my Playstation 5 as a light with a stand.

The original design was created by Christopher Quinalty: https://www.thingiverse.com/cq842000/designs

I tried printing his design of his Sony Play Bust with an Elegoo Mars 2 Pro. After the 3rd attempt i gave up on it.

I had to scale it down a little bit but still couldn't get a good result based on the hollow design. The walls ended up being only 0.4mm thick. Therefore, if you touch it a little too rought it will break, as it did for me.

So, I decided to re-design it a bit. After I finished the Logo I was like yea, why not making it shine even more!

I bought a 30 LED/1m 5V with remote LED-strip for 10$ on Amazon and designed a socket with Playstation on the front. (For Xbox don't worry, I've uploaded a clean socket as well for you guys!)

With the 30 LED/1m you can fit up to 10 LED's around the socket as you can see down below in this post.

I fixed the strip inside and the cable which goes out of the socket with some hot glue. You know, just in case. After glueing everything together, I coated it with some clear varnish.

I hope you enjoy it and please support the original designer as well!

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

No

Supports:

No

Resolution:

0.16

Infill:

20

Filament:

PLA Vertigo Grey

Notes:

The Logo was printed with a transparent blue on a Elegoo mars 2 Pro SLA Printer with 100% infill.

Assembly:

The Logo should fit quite nicely into the socket. Just put some Glue on it if you like. Enjoy!
